Model: PU220-01 PU220-02 PU220-03 PU220-04 PU220-06 PU220-08
Working Medium: Gas,Water,Oil
Motion Type: Direct acting
Valve Type: Normally closed
Effective Cross Section Area: 1.5 2.3 8.0 13 20 25
CV valve: 0.10 0.18 1.00 4.00 8.60 11.00
Port size: 1/8" 1/4" 3/8" 1/2" 3/4" 1"
Recomended Fliud Viscosity: 50CST
Working Pressure: 0~0.7MPa
Max. Test Pressure: 1.05MPa
Max. Ambient Temperaure: -5~80oC
